Premium Effcient Stainless Steel motor NEMA
Inquire NowDescription
The Premium Efficient Stainless Steel Motor NEMA is a top-tier solution designed for a variety of demanding applications. This motor is perfect for food processing, packaging, and environments that are highly corrosive. With its robust stainless steel construction, it ensures exceptional durability, even in the harshest conditions. The motor is available in a range of horsepower from 1/3 HP to 10 HP and can operate efficiently at multiple speeds: 3600, 1800, and 1200 RPM. Designed with versatility in mind, it is inverter-duty rated and offers optimal performance across different voltages.
Specifications
| Feature | Details |
|---|---|
| Horsepower | 1/3 HP to 10 HP |
| RPM | 3600, 1800, 1200 |
| Frame Size | 56-256 |
| Voltage | 208-230/460 Volt |
| Inverter Duty Rating | 15:1 CT, 30:1 VT |
| Service Factor | 1.15 SF @ 60 Hz, 1.0 SF @ 50 Hz |
| Material | Stainless Steel |
| Conduit Box | Round, Epoxy Sealed |
| Nameplate | Laser Etched |
| Enclosure Type | TEFC or TENV |
| Protection Rating | IP66 |
| Optional Features | C face / Footless, Square Conduit Box, IP55 |
Additional Information
- Double VPI insulation for enhanced durability.
- Shaft slinger on both ends of the motor to prevent moisture intrusion.
- O-Rings installed on endbells to further eliminate moisture.
