Proble cable for ultrasound equipment
Inquire NowDescription
Introducing a specialized cable designed specifically for ultrasound equipment, this micro-coaxial cable excels in performance and reliability. It boasts exceptional resistance to bending and twisting, ensuring durability in demanding environments. With effective anti-EMI properties, the cable guarantees high-speed signal transmission, making it an essential component in ultrasound technology. The flame-resistant construction adds an additional layer of safety and reliability, making it ideal for medical and industrial applications.
Specifications
| Attribute | Details |
|---|---|
| Temperature Ranges | -15℃ to 80℃ |
| Characteristic Impedance | 50±5Ω |
| Center Conductor Resistance | ≥5000MΩ/km |
| Dielectric Strength | AC500V for 1 min |
| Capacitance | 1KHz: 110±20nF/m |
| Insulation Resistance | Min 1000MΩ.km |
| Attenuation | Max: 0.61db/m |
| Rated Voltage | 30V |
| Conductor | Stranded alloy wire |
| Insulation | Fluoroplastic |
| Tape | PET |
| Shield 1 | Alloy wire Jacket 1: PET |
| Shield 2 | Alloy wire Jacket 2: Please see attached list |
Additional Information
This micro-coaxial cable is designed for optimal performance in ultrasound applications, ensuring reliable signal quality and minimal interference. Its robust construction makes it suitable for various demanding environments.
