process pressure gauge
Inquire NowDescription
The process pressure gauge is an essential tool designed to monitor pressure levels in various applications, ensuring increased safety and reliability. Engineered with a liquid-filled case, it is specifically suited for environments with high dynamic pressure pulsations or vibrations, making it ideal for use in harsh conditions. This gauge is compatible with both corrosive environments as well as gaseous or liquid media that do not obstruct the pressure system, providing versatility in a wide range of industrial applications.
Specifications
| Attribute | Details |
|---|---|
| Normal Size | 4.5″ (115mm) |
| Pressure Range | -1 Bar (-30″Hg) – 0 – 1000 Bar (15000 Psi) |
| Accuracy | ±1%, ±1.6% |
| Operating Temperature | -40°C to +60°C |
| Case Material | Polypropylene |
| Bezel Material | Polypropylene |
| Bourdon Tube Material | Copper Alloy or Stainless Steel |
| Connection Material | Brass or Stainless Steel |
| Movement Material | Brass or Stainless Steel |
| Dial Material | Aluminum |
| Pointer Material | Aluminum |
| Window Material | Polycarbonate or Glass |
| Thread Options | 1/8″, 1/4″, 3/8″, 1/2″; PT (BSPT, ZG), BSP (G, PF), NPT etc. |
| Liquid Filling | Glycerin or Silicone |
| Gaskets Filling Cap | Nitrile or Silica Gel |
