PS series standard end suction centrifugal bare shaft pump
Inquire NowDescription
The PS Series Standard End Suction Centrifugal Bare Shaft Pump is an innovative solution designed specifically for fire fighting applications, featuring a patented original design by PURITY. This pump is engineered to provide reliable performance across a wide range of applications, including water supply, pressure boosting, irrigation, and industrial uses.
Available with both square and round motor configurations, the pump is powered by a high-efficiency YE3 motor that boasts an IP55 Class F protection rating. Its robust construction includes an anti-corrosive coated pump case, a stainless steel AISI 304 impeller, and a durable stainless steel AISI 304 shaft. The galvanized counter flange is reinforced with bolts, nuts, and gaskets, ensuring longevity and reliability under various conditions.
With models capable of handling capacities ranging from 80 to 5000 US GPM, this pump is suitable for use with clean water and non-aggressive liquids. It adheres to the EN733 standard, ensuring optimal performance and safety.
Specifications
| Attribute | Details |
|---|---|
| Motor Type | YE3 high efficiency motor |
| Protection Class | IP55 Class F |
| Impeller Material | Stainless Steel AISI 304 or Brass |
| Shaft Material | Stainless Steel AISI 304 |
| Max Capacity | 5000 US GPM |
| Liquid Temperature Range | -10℃ to +120℃ |
| Ambient Temperature | Up to +50℃ |
| Max Working Pressure | 16 bar |
| Continuous Service Class | S1 |
| Patents | Registered model PST, Registered Patent Design n° 201530478502.0 |
Additional Information
- Quality NSK bearing for enhanced durability
- Wear-resistant mechanical seal for prolonged service life
- Recommended for use in fire fighting, cleaning sets, and water circulation tasks
