PURITY Same Port Centrifugal Pump PW
Inquire NowDescription
The PURITY Same Port Centrifugal Pump PW is a cutting-edge solution designed for efficient and reliable fluid transfer. This centrifugal pump boasts a patented original design by PURITY, ensuring superior performance in a variety of applications. Available with both square and round motors, it utilizes a YE3 high-efficiency motor with IP55 class F protection, making it suitable for challenging environments. The pump’s case is coated with anti-corrosive material, enhancing its durability, while the galvanized counter flange comes complete with bolts, nuts, and gaskets for easy installation. Its quality construction includes NSK bearings and a wear-resistant mechanical seal, ensuring long-lasting operation.
Specifications
| Feature | Detail |
|---|---|
| Design | New same DN centrifugal pump, patented original design |
| Motor Type | Square motor & round motor available |
| Motor Efficiency | YE3 high efficient motor, IP55 class F protection |
| Pump Case | Anti-corrosive coating |
| Impeller Material | Stainless steel AISI 304 or cast iron |
| Shaft Material | Stainless steel AISI 304 or galvanized iron |
| Working Pressure | Max. 16 bar |
| Liquid Temperature | -10℃ to +120℃ |
| Ambient Temperature | Up to +50℃ |
| Continuous Service | S1 |
Additional Information
- Applications: Ideal for clean water and fluids that are not chemically aggressive. Suitable for water supply, pressure boosting, firefighting sets, irrigation, and industrial applications.
- Using Limits:
- Liquid temperature between -10℃ and +120℃
- Ambient temperature up to +50℃
- Max. working pressure 16 bar
- Continuous service S1
- Patents: Registered model PW, Patent Design no 201530478502.0
