PV Branch Cable
Inquire NowDescription
The PV Branch Cable is a state-of-the-art solution designed for reliable solar energy connections. Crafted from anti-aging and UV-resistant materials, this cable ensures longevity and performance even in harsh outdoor conditions. With low heat and power loss, it is engineered for high robustness and provides a secure connection. Its convenient installation and strong compatibility make it an essential choice for solar panel setups.
Specifications
| Attribute | Details |
|---|---|
| Type | PV-ONBC3 |
| Description | 3 branch cable |
| Connector | 1 male to 3 female or 1 female to 3 male |
| Main cable length | 60 cm |
| Branch cable length | 10 cm |
| PIN diameter | 4 mm |
| Rated voltage | 1500V DC (IEC) |
| Rated current | 30 A |
| Impulse withstand voltage | 6 kV (50Hz, 1 min) |
| Ambient temperature range | -40℃ to 90℃ (IEC) |
| Insulation material | PPE/PA |
| Contact material | Tin plated copper alloy |
| Contact resistance | 0.5 mΩ |
| Protection degree | IP67 |
| Flame class | UL94-V0 |
| Safety class | Class II |
Additional Information
- Designed for optimal performance in challenging outdoor environments.
- Ideal for solar panel installations requiring robust and efficient cabling solutions.
