Railway 10′ Containerized Highly-customized Sets Diesel Generator
Inquire NowDescription
The Railway 10′ Containerized Highly-customized Sets Diesel Generator is an innovative power solution designed specifically for government projects in Oceania. This highly customized generator features a robust Deutz air-cooled engine paired with Stamford alternators, ensuring reliable and efficient performance in various applications. Enclosed within a 10-foot containerized canopy, it houses two 80kVA sets, providing substantial power output while maintaining ease of transport.
This generator is equipped with a uniquely designed control system that includes DSE7320, Siemens PLC, SOCOMEC ATS, and ABB motorized breakers to suit specific site applications. Additionally, it boasts a 1000L base fuel tank and is optimized for operation in temperatures up to 40 degrees Celsius, complete with pre-filters on air inlet louvers for enhanced air quality and performance.
Constructed from heavy-duty galvanized sheet metal, the canopy is designed to prolong service life while minimizing noise levels, making it an ideal choice for mining and remote areas. The generator also features stainless steel external hardware, a lockable fuel filler, crimped fuel lines, and a radiator collective bottle, ensuring durability and safety.
Overall, this containerized type generator is well-received in the mining industry, providing an environmentally-friendly solution with a fully bunded base fuel tank that prevents spills on the ground.
Specifications
| Attribute | Detail |
|---|---|
| Generator Type | Containerized Diesel Generator |
| Engine | Deutz Air-cooled |
| Alternator | Stamford |
| Output | 2 x 80kVA |
| Container Size | 10 Foot |
| Fuel Tank Capacity | 1000L |
| Operating Temperature | Up to 40°C |
| Canopy Material | Galvanized Sheet Metal |
| Base Type | Heavy-duty Mine Spec Skid |
| Weight | Not specified |
Additional Information
- Improved air flow and ambient temperature design ensures maximum generator performance.
- Customized built-in high-performance residential muffler minimizes noise levels.
- Standard features include top lifting points, forklift pockets, and robust steel lockable fuel inlet with electrical fuel gauge.
- User-friendly external power outlet flap for ease of access.
- Environmental-friendly fully bunded base fuel tank prevents spills.
- Earth strap fitted on all canopy doors for safety.
- Holistic disassembly structure with large doors for convenience in daily checks and maintenance.
- High-quality outdoor powder coating protects against rust, corrosion, and UV radiation.
