Rain gutter metal profile making roll forming machine
Inquire NowDescription
The Rain Gutter Metal Profile Making Roll Forming Machine is designed for precision and efficiency in producing high-quality metal gutters. This innovative equipment allows for seamless bending and forming of steel plates, ensuring a durable and aesthetically pleasing product. The machine integrates various components including an uncoiler, feed leading table, main machine, formation cutting device, hydraulic system, and control system, providing a comprehensive solution for gutter manufacturing. Its robust design enhances project integrity and longevity compared to traditional materials, making it a valuable asset for any construction or manufacturing operation.
Specifications
| No. | Main Parameter | Details |
|---|---|---|
| 1 | Suitable to Process | Color steel plate |
| 2 | Width of the Plate | 200-600mm |
| 3 | Rollers | 14-16 rows |
| 4 | Dimensions | 8.6 * 0.8 * 1.2 m |
| 5 | Power | 4+3 kW |
| 6 | Thickness of the Plate | 0.3-0.8 mm |
| 7 | Productivity | 8-12 m/min |
| 8 | Diameter of the Roller | 52 mm |
| 9 | Weight | About 4.5 T |
| 10 | Voltage | 380V 50Hz 3 phases |
| 11 | Rolling Material | Carbon Steel 45# |
| 12 | Material of the Cutting Plate | Cr12 |
| 13 | Processing Precision | Within 1.00 mm |
| 14 | Control System | PLC control |
| 15 | Side Panel of Machine | 14 mm |
| 16 | Main Structure of the Machine | 300 H steel |
Additional Information
Packaging Details: The main machine is nude, while the computer control box is packed with a wooden frame. Delivery is expected within 20 days.
