RCBO Residual Current Circuit Breaker with Over Current Protection EBS6BLE
Inquire NowDescription
The EBS6BLE is a state-of-the-art Residual Current Circuit Breaker (RCBO) designed for advanced electrical safety. This device combines residual current protection with overcurrent protection, ensuring a reliable safeguard against electric shocks and fire hazards due to insulation faults. Its versatile application makes it suitable for residential, commercial, and industrial use. The device features a switching and isolation function, overload protection, and short circuit protection, making it a crucial component in any electrical system.
- Switching and isolation function
- Protection against electric shock from direct or indirect contact
- Fire hazard protection from insulation faults
- Applicable in housing, tertiary sectors, and industrial settings
- Overload and short circuit protection
Specifications
| Attribute | Details |
|---|---|
| Model Name | EBS6BLE |
| Standard | IEC61009-1 |
| Poles | 1P+N |
| Rated Current In(A) | 6, 10, 16, 20, 25, 32A |
| Rated Voltage Un(V) | 240V AC 50/60Hz |
| Tripping Characteristic | B, C |
| Rated Sensitive Current, I△n(mA) | 30 |
| Rated Short Circuit Breaking Capacity | 4,500 |
| Protection Grade | IP20 |
| Installation | Installed on 35mm DIN rail |
| Ambient Temperature | -5~+40℃ (average value cannot exceed +35℃ within 24h) |
| Altitude | ≤2,000m |
| Relative Humidity | ≤95% |
| Pollution Level | II |
| Installation Location | Mount in areas with no excessive vibration or impact |
Additional Information
The EBS6BLE RCBO is engineered to provide exceptional reliability and safety. It is essential to install the unit in a location devoid of significant vibrations or impacts to maintain its operational integrity. Regular maintenance and testing are recommended to ensure ongoing effectiveness in protecting electrical systems.
