Residual Current Circuit Breaker with Overcurrent Protection
Inquire NowDescription
The Residual Current Circuit Breaker (RCCB) with Overcurrent Protection is an essential safety device designed to protect electrical installations from current leakages and overloads. This reliable device is compliant with the IEC/EN 61009-1 standard, ensuring high safety and performance levels. Its operating characteristic is AC, making it suitable for a wide range of applications.
Equipped with an instantaneous tripping current curve of B and C, this RCCB ensures rapid response to electrical faults. It features a compact design with 1 Pole + Neutral configuration, making it perfect for residential and commercial environments. Available in various rated current options of 6, 10, 16, 20, 25, 32, and 40 Amps, it allows for flexible installations based on specific needs.
With a rated operation voltage of 230/240V and a frequency of 50/60Hz, this circuit breaker offers exceptional performance. The rated impulse withstand voltage of 4kV and a protection index of IP20 ensure durability and resilience, while the ambient temperature range of -25℃ to +55℃ provides versatility in various environments.
Specifications
| Feature | Specification |
|---|---|
| Standard | IEC/EN 61009-1 |
| Operating Characteristic | AC |
| Instantaneous Tripping Current Curve | B, C |
| Number of Poles | 1P + N |
| Rated Current | 6/10/16/20/25/32/40 A |
| Rated Operation Voltage Ue | 230/240V |
| Rated Frequency | 50/60Hz |
| Rated Impulse Withstand Voltage Uimp | 4kV |
| Rated Residual Operating Current IΔn | 30 mA |
| Rated Short-Circuit Capacity (ICN) | 4.5 kA |
| Protection Index | IP20 |
| Ambient Temperature | -25℃ ~ +55℃ |
Additional Information
- Ideal for both residential and commercial applications.
- Ensures safety by disconnecting electrical circuits during fault conditions.
