Description
The RG6 with messenger coaxial cable is specifically designed for optimal data communication in CCTV systems. With a 50Ω impedance, this cable ensures reliable signal transmission essential for surveillance applications. Its robust construction includes a high-quality inner conductor and multiple layers of shielding, providing superior protection against interference. This versatile cable is engineered to withstand a wide operating temperature range, making it suitable for diverse environments.
Specifications
| Attribute | Details |
|---|---|
| Inner Conductor | 1.02mm BC or CCS |
| Insulation | 4.57mm Foamed Polyethylene |
| Shield 1 | Al Foil |
| Shield 2 | BC or TC or AA wire Braiding |
| Messenger | 1.30mm Steel wire |
| Jacket | 6.86+2.80mm PVC or PE |
| Flame Retardant Grade | CMX, CM, CMR, CATVX, CATV, CATVR |
| Operating Temperature | -25 to 70℃ or -40 to 70℃ |
| Reference Standard | MIL-C-17 |
Additional Information
Ensure proper installation techniques to maximize performance and longevity of the RG6 with messenger coaxial cable. This cable is suitable for various applications beyond CCTV, making it a reliable choice for any professional wiring needs.
