Ricardo series 42kw Power machinery diesel engine R4105P
Inquire NowDescription
The Ricardo Series R4105P Power Machinery Diesel Engine is a cutting-edge four-stroke, water-cooled, in-line diesel engine designed specifically for robust performance in various applications. Capable of delivering an output of 42kW at 1500rpm and 48kW at 2000rpm, this engine is engineered for high efficiency and reliability. Its advanced direct injection combustion chamber technology enhances fuel economy while ensuring easy starting even in temperatures as low as -10°C without preheating.
This diesel engine features a bore of 105mm and a stroke of 125mm, offering an impressive displacement of 4.33 liters per cylinder, and is available in configurations of four and six cylinders. The R-series engines are recognized for their low fuel consumption, high operational reliability, and excellent torque performance, making them ideal for power generators, marine engines, agricultural machinery, and construction equipment.
The R4105P is manufactured using advanced technology and expertise transferred from Ricardo in the UK, coupled with European manufacturing equipment, ensuring that it meets the highest standards in diesel engine performance and durability.
Specifications
| Engine Series/Model | Bore (mm) | Stroke (mm) | Displacement (liters/cylinder) | Cylinders NO. L = In-Line | KW@1500rpm | KW@2000rpm | Dimension (mm) |
|---|---|---|---|---|---|---|---|
| R4105P | 105 | 125 | 4.33 | L 4 | 42 | 48 | 1400*800*1200 |
| ZH495G | 95 | 115 | 3.26 | L 4 | 26.5 | 35.3 | 1360*640*920 |
| ZH4100G | 100 | 115 | 3.61 | L 4 | 30.1 | 39 | 1360*640*1000 |
| R6105P | 105 | 125 | 6.49 | L 6 | 58 | 72 | 1830*740*1040 |
| 6126IZLP | 126 | 155 | 11.596 | L 6 | 275 | 2730*780*1539 |
Additional Information
- First overhaul period: 8000 hours
- Ideal for power generation, marine engines, agricultural machinery, and construction equipment.
- Emphasizes low emissions and low maintenance costs.
