Ride-on Type Rice Transplanter 2ZW-6D2
Inquire NowRide-on Type Rice Transplanter 2ZW-6D2
Jiangsu Wallong-Hsin Machinery Engineering Corp. Ltd. is a state-owned company, we are subsidiary of China National Machinery Industry Corporation (SINOMACH Group), under the management of Chinese Academy of Agricultural Mechanization Sciences (CAAMS). We have specialized in agricultural machinery for more than 20 years.
We have professional engineer team and experienced pre-sale and after-sale technicians. Our products has helped thousands farmers all over the world.
2ZG-630A is new generation of rice transplanter with the characteristics of comfortable driving, low noise, high reliability, excellent operating performance.
The transplanter is equipped with Yanmar brand diesel engine (18.5kw), the power is strong and stable.
Specification:
| Model | 2ZW-6D2 | ||
| Type | Ride-on type | ||
| Drive type | Four-wheel drive | ||
| Dimensions | Overall length (mm) (transportation/operation) | 3090 / 3050 | |
| Overall width (mm) (transportation/operation) | 2220 / 2280 | ||
| Overall height (mm) (transportation/operation) | 2580 / 2580 | ||
| Weight ( kg ) | 820 | ||
| Engine | Model | Yanmar Brand: 3TNM72 | |
| Type | Vertical, water-cooled, three-cylinder diesel engine | ||
| Total displacement (L) | 0.904 | ||
| Rated power (kw/RPM) | 18.5 / 3600 | ||
| Applicable fuel | High-quality diesel fuel | ||
| Fuel tank capacity ( L ) | 34 | ||
| Starting system | Electric start | ||
| Fuel consumption (kg/ha) | 2.2-5.6 | ||
| Traveling | Wheel | Front wheel type | Explosion-proof tire |
| Rear wheel type | Rubber lug wheel | ||
| Front wheel diameter x width (mm) | φ650 x 95 | ||
| Rear wheel diameter x width (mm) | φ950 x 50 | ||
| Wheel-track (mm) | 1200 | ||
| Steering type | Overall hydraulic steering | ||
| Gearshift method | HST | ||
| Number of shifting positions | Main shifting: forward & backward 5 stage (sub-transmission： 2 stages; Anti-sinking: 2 stages) |
||
| Planting portion | Number of planting rows | 6 | |
| Row distance (mm) | 300 | ||
| Hill space (mm) | 100, 120, 140, 160, 180, 210, 240 | ||
| Planting depth (mm) | 10 – 55 [ 7 stages ] | ||
| Number of seedlings per hill | Number of lateral movements (20, 18, 16, 14) | ||
| Vertical taking depth (8mm – 18mm) | |||
| Balancing mechanism type | Mechanical | ||
| Planting speed ( m/h ) | 0 – 1.65 | ||
| Min. ground clearance (mm) | 500 | ||
| Planting Density / No. of hills per 3.3m2 | 45-108 | ||
| Seeding condition | Seedling type | Seedling mat | |
| Seedling height (mm) | 80 – 250 | ||
| Number of leaves | 2.0 – 4.5 | ||
| Warning device | battery charging, oil pressure, backward, water temperature, lack of seedling | ||
| Operation efficiency (ha/h) | 0.2 – 0.7 | ||
* Specifications are subject to change without prior notice.
