Road Roller- JMG165
Inquire NowDescription
The Road Roller JMG165 is a robust construction machine designed for efficient compaction of asphalt and soil. Powered by a reliable Cummins diesel engine, this roller ensures optimal performance with a rated power of 125kw (170 hp) and a rated rotating speed of 2300 rpm. It features a luxurious cab equipped with an air conditioner, providing the driver with a broad view and comfort during operation. The advanced hydraulic system, utilizing imported seals and a HUSCO Multi-way Valve, guarantees safety and reliability. With multi-optional components like a front dozer and rear ripper, this versatile machine meets various construction needs.
Key features include a Meritor axle tailored for motor graders, a gearbox adopting German ZF technology, and all-hydraulic control for the blade, making it a top choice for heavy-duty tasks.
Specifications
| Attribute | Unit | Value |
|---|---|---|
| Engine | Cummins 6BT5.9-C170 | |
| Rated Power | KW | 125kw / 170 hp |
| Rated Rotating Speed | rpm | 2300 |
| Displacement | L | 5.9 |
| Max Ground Clearance | mm | 430 |
| Min Turning Radius | m | 7.8 |
| Frame Articulation | L/R | 25° |
| Steering Arc of Front Axle | L/R | 45° |
| Maximum Traction | KN | 82 |
| Forward Speed 1st | km/h | 5 |
| Forward Speed 2nd | km/h | 8 |
| Forward Speed 3rd | km/h | 11 |
| Forward Speed 4th | km/h | 19 |
| Forward Speed 5th | km/h | 23 |
| Forward Speed 6th | km/h | 38 |
| Max Reverse Speed | km/h | 23 |
| Moldboard Max Slope Cutting Angle | ° | 90° |
| Dimension (L*W*H) | mm | 9123*2610*3440 |
| Operating Weight | kg | 15,000 |
| Fuel Tank Capacity | L | 290 |
| Hydraulic Oil Tank Capacity | L | 110 |
Additional Information
The Road Roller JMG165 comes with an international warranty service, ensuring peace of mind for users. Its luxurious features and advanced technology make it an ideal choice for construction projects requiring precision and efficiency.
