Roof Tile Forming Machine
Inquire NowDescription
The Steel Roof Tile Forming Machine is a robust and efficient solution designed for the production of high-quality steel roof tiles. This machine boasts a user-friendly operation, making it suitable for a wide range of applications in the roofing industry. Constructed with pre-painted and galvanized steel coil, it ensures durability and longevity while delivering impressive results.
With a maximum forming speed of 2-3 m/min and the ability to handle steel thicknesses ranging from 0.3 to 0.6 mm, this machine is engineered to meet the demands of various roofing projects. The roller material, made from #45 steel with hard chrome treatment, enhances its performance and reliability. The intuitive touch screen and button controls allow for easy operation, making it accessible for all users.
Specifications
| Product Name | Steel roof tile forming machine |
|---|---|
| Material | Pre-painted & galvanized steel coil |
| Thickness (mm) | 0.3-0.6 |
| Yield Stress (MPa) | Q235-345 |
| Max Forming Speed (m/min) | 2-3; 5-6 |
| Roller Material | #45 steel with hard chrome treatment |
| Roller Driven Type | Chain transmission |
| Controller | PLC |
| Operation | Touch screen and button |
| Hydraulic System Pressure (MPa) | 12 |
| Main Motor Power (KW) | 5.5 |
| Hydraulic Station Motor Power (KW) | 5.5 |
| Dimension (L*W*H) | About 8000*1500*1500 mm |
| Weight (KG) | About 8000 |
Additional Information
Our service includes pre-sales consulting, technical guidance, and a one-year warranty period for the machine. We also provide spare parts at cost price after the warranty period and long-term technical assistance. For inquiries regarding quality control, we comply with ISO 9001 standards, ensuring every machine undergoes thorough testing before shipment.
