Description
The SATV optical transmitter is a versatile and high-performance device designed for modern FTTH (Fiber To The Home) networks, ensuring seamless compatibility with GPON, EPON, and various FTTx PON technologies. This transmitter excels in delivering exceptional signal quality and stability, making it an ideal choice for both residential and commercial applications. With a wide operating frequency range from 47 to 2150 MHz, it guarantees excellent linearity and flatness, ensuring reliable performance under diverse conditions. The transmitter utilizes advanced GaAs amplifier active devices and ultra-low noise technology for optimal output, paired with a compact design for easier installation.
- Designed for FTTH networks
- Wide operating frequency range: 47-2150MHz
- Excellent linearity and flatness
- Single-mode fiber high return loss
- Ultra low noise technology
- Compact design for easy installation
- Red-LED power indicator
- Output 13/18V, 0/22KHz for LNB operation
Specifications
| Item | Unit | Description | Remark |
|---|---|---|---|
| Customer Interface | |||
| RF Connector | F-female | ||
| Optical Connector | SC/APC | ||
| Power Supply | F-female | ||
| Optical Return Loss | dB | ≥45 | |
| Output Optical Wavelength | nm | 1550 | |
| Output Optical Power | mW | 10 | |
| Optical Fiber Type | Single Mode | ||
| Frequency Range | MHz | 47-2150 | |
| CATV Flatness | dB | ±0.75 | |
| Input Impedance | Ω | 75 | |
| Dimensions | mm | 100*98*28 |
Additional Information
- Power Supply: 12 VDC
- Power Consumption: <3 W
- Maximum Current: 500 mA
- 22KHz Accuracy: 22±4 KHz
