SB7-CA35 sb7 green push button urinal flush single flush button
Inquire NowDescription
The SB7-CA35 Green Push Button Urinal Flush is an innovative solution designed for efficient water management in urinals. This single flush button operates flawlessly, controlling circuits for AC voltages up to 660V at 50Hz or 60Hz, and DC voltage below 400V. Crafted with a robust zinc alloy body and high-grade anti-flame plastic, it ensures durability and safety. The specially designed silver alloy contacts provide excellent resistance against electrical erosion, ensuring longevity and reliability.
This push button series is not only functional but also versatile, suitable for controlling signals, interlocking purposes, and operating electrical appliances with AC voltage up to 380V at 50Hz and DC voltage below 380V. Its compliance with GB/T14048.1 and IEC60947-5-1, along with CE, ISO9001, ROHS, and UL certifications, guarantees that you are investing in a high-quality product.
Specifications
| Main Technical Parameter | Description |
|---|---|
| Rated Insulation | AC 600V (50Hz/60Hz) |
| Insulation Resistance | ≥50MΩ |
| Conventional Heating Current | 10A |
| Contact Resistance | ≤25MinΩ |
| Mechanical Life | 100×10000 pushbutton / 50×10000 selector switch |
| Electrical Life | 500×10000 pushbutton / 25×10000 selector switch |
| Continuous Working Life | 10x10000h |
| Brightness | 60cd/m² |
Additional Information
- Ideal for use in commercial and public restroom settings.
- Easy to install and operate, reducing maintenance time.
- Environmentally friendly due to its energy-efficient design.
