SB7-CS545 sb7 green push button urinal flush single flush button
Inquire NowDescription
The SB7-CS545 Green Push Button Urinal Flush is an innovative solution designed for efficient water management in urinals. This push button features a robust construction, combining zinc alloy and high-grade anti-flame plastic, making it durable and suitable for different applications. With the ability to control circuits of AC voltage up to 660V and DC voltage below 400V, this button is perfect for various signaling and interlocking purposes. Its advanced design meets strict compliance with international safety standards, ensuring reliable functionality and user safety.
Specifications
| Parameter | Button | Signal Lamp |
|---|---|---|
| Rated Insulation | AC 600V (50Hz/60Hz) | Insulation Resistance |
| Conventional Heating Current | 10A | Contact Resistance |
| Insulation Resistance | ≥50MΩ | Pf Withstand Voltage |
| Contact Resistance | ≤25MinΩ | Voltage Wave |
| Mechanical Life | 100×10000 | Brightness |
| Electrical Life | 500×10000 | Continuous Working Life |
Additional Information
- Ideal for use as indicating signals, warning signals, and emergency signals.
- Complies with GB/T14048.1 and IEC60947-5-1 standards.
- CE, ISO9001, ROHS, and UL certified for quality assurance.
