Description

The SBG200 HDPE / PP double wall corrugated pipe production line is designed for manufacturing high-quality double-wall corrugated pipes with diameters ranging from 50mm to 200mm. This innovative production line utilizes advanced technology to create pipes that boast high stiffness, excellent strength, and lightweight properties. The double-wall structure not only enhances noise damping but also provides exceptional resistance to ultraviolet light, ensuring a long service life.

Equipped with a high-speed single-screw extruder, the production line features a tube slotting design and a low-noise fan, contributing to an efficient and quiet operation. The inner and outer layers of the pipes are produced using two independent feeding systems, allowing for the use of different materials for optimal performance. The horizontal molding machine incorporates a chain drive design along with an open water cooling system, significantly improving production speed while maintaining accuracy and quality. An advanced auto-lubrication system minimizes wear and tear, thereby extending the service life of the forming modules.

The extrusion die, designed with a special spiral structure, ensures a clean flow channel that effectively reduces internal stress and maintains uniform thickness across both the inner and outer layers. The cutting machine features joint control that is both electrical and pneumatic, providing smooth and precise pipe cutting with simple operations and a reliable fixed-length mechanism.

Specifications

Additional Information

– The production line features a low-noise fan for quieter operation.
– The system allows for simultaneous drive to ensure high production accuracy.
– The cutting mechanism is designed for simple operation and sensitive adjustments.
