scaffolding planks deck roll forming machine
Inquire NowDescription
The Automatic Sheet Steel Cold Plate Walk Board U Scaffolding Planks Deck Roll Forming Machine is a state-of-the-art solution designed for efficient and precise production of scaffolding planks. This machine boasts exceptional compressive strength and flatness, ensuring high-quality output with every cycle. It features automatic measuring, cutting, and punching capabilities, significantly enhancing productivity and reducing labor costs. Ideal for large and medium-sized civil construction projects, this machine is perfect for creating structural supports in warehouses, exhibition buildings, theaters, and stadiums.
Specifications
| Parameter | Description |
|---|---|
| Suitable to Process | Color steel plate, galvanized sheet, aluminum coils, etc. |
| Width of Feeding Material | 1250mm |
| Roller Station | 14 rows |
| Thickness of Feeding Material | 0.3-0.8mm |
| Productivity | 8-12m/min |
| Rollers’ Material | 45# steel with chrome on the surface |
| Diameter of Shaft | 80mm |
| Voltage | 380V 50Hz 3 phases |
| Wall Thickness of Main Forming Machine | 16mm steel plate |
| Main Forming Machine Body | 300 mm H steel |
Additional Information
For optimal performance, ensure regular maintenance and proper calibration of the machine. This will enhance its longevity and maintain the quality of the scaffolding planks produced. The machine is designed for easy installation and can be integrated into existing production lines with minimal disruption.
