Shantui 220 Horsepower SD22W Rocks Bulldozer
Inquire NowDescription
The SD22W rock bulldozer by Shantui is expertly engineered to tackle the most challenging rock working conditions. With its advanced technological features, this powerful machine offers high reliability, low fuel consumption, and straightforward maintenance. Its design not only enhances productivity but also ensures cost-effectiveness compared to other bulldozer brands globally.
Shantui bulldozers, including the SD22W, stand out in the market for their exceptional durability and performance. Perfectly suited for heavy-duty applications, this bulldozer excels in mining operations, efficiently managing coarse sands, stones, and decomposed rocks.
With a reputation for excellence in Africa, Europe, America, and Asia, the SD22W is a top choice among professionals for its outstanding value and performance.
Specifications
| Specification | Details |
|---|---|
| Model | SD22W |
| Dimensions (LxWxH, mm) | 5750 x 3725 x 3395 |
| Operating Weight (t) | 23.44 |
| Engine | Cummins NT855-C280S10 / Weichai WD12G240E26 |
| Gross Power (kW/HP/rpm) | 175/235/1800 |
| Net Power (kW/HP/rpm) | 162/220/1800 |
| Gradeability (°) | 30 |
| Blade Type | Straight Tilt Blade / Angle Blade |
| Blade Size (WxH, mm) | 3725 x 1315 / 4365 x 1055 |
| Dozing Capacity (m³) | 6.4 / 4.7 |
| Max Drop Below Ground of Blade (mm) | 540 / 535 |
| Lift Height of Blade (mm) | 1210 / 1290 |
| Ripper Type | Single Ripper / Three-Shank Ripper |
| Ripping Depth of Ripper (mm) | 695 / 665 |
| Lifting Height of Ripper (mm) | 515 / 555 |
| Number of Carriers (each side) | 2 |
| Number of Track Rollers (each side) | 6 |
| Number of Track Shoes (each side) | 38 |
| Width of Track Shoe (mm) | 560 |
| Track Gauge (mm) | 2000 |
| Ground Length and Pressure (mm/MPa) | 2730 / 0.077 |
| Pitch (mm) | 216 |
| Forward Speed (km/h) | 0-3.6 / 0-6.5 / 0-11.2 |
| Reverse Speed (km/h) | 0-4.3 / 0-7.7 / 0-13.2 |
Additional Information
Product Strengths:
The SD22W is built with high-strength, wear-resistant rock blades and push rods, making it ideal for heavy-load conditions.
Applicable Working Conditions:
Designed for mining operations involving coarse sands, stones, and decomposed rocks.
Current Sales Conditions:
This bulldozer enjoys popularity worldwide, reflecting its quality and performance.
