Shunt Release Auxiliary Device MCCB Accessory
Inquire NowDescription
The Shunt Release Auxiliary Device is an essential accessory for MCCB (Molded Case Circuit Breaker) operations. Designed for remote control, the Shunt Release facilitates the instantaneous disconnection of the circuit, enhancing both safety and efficiency in electrical systems. With factory-connected wiring for ease of use, it is straightforward for users to integrate into existing setups, allowing for quick adjustments as needed.
Why Choose Us?
- Extensive development history.
- Diverse range of circuit breakers available.
- Strong customer marketing support.
- Robust research and development initiatives.
- Patent protection for our technologies.
- Government honors and certifications.
Specifications
| Component | Description |
|---|---|
| Shunt Release Type | Electrical accessory for remote controlling MCCB |
| Supply Voltage Range | (0.7-1.1) x Us |
| Rated Control Supply Voltage | AC 50Hz, 220V, 380V |
| DC Voltage Options | 110V, 220V |
| Power Loss | 150V |
Additional Information
The wiring diagram for the Shunt Release is essential for proper installation:
- SB2 – Opening Push-button (ready by user)
- P3, P4 – Terminal numbers
- Us – Control power
- QF – Auxiliary contact
