Single Row Angular Contact Ball Bearing
Inquire NowDescription
Experience superior performance with the Single Row Angular Contact Ball Bearing, designed for precision and reliability in various applications. This type of bearing allows for the accommodation of axial loads in one direction, making it ideal for high-speed and high-precision machinery. Its angular contact design ensures optimal stability and durability, reducing friction and heat generation, resulting in extended lifespan and efficiency.
Specifications
| Principal Dimensions (mm) | Bearing No. | Dynamic Load Rating (Cr) | Static Load Rating (Cor) | Grease Speed Rating (rpm) | Oil Speed Rating (rpm) | Weight (kg) |
|---|---|---|---|---|---|---|
| d: 10 D: 26 B: 8 B1: 0.3 r(min): 0.15 |
7000C | 4920 | 2250 | 19000 | 28000 | 0.018 |
| d: 12 D: 28 B: 8 B1: 0.3 r(min): 0.15 |
7001C | 4750 | 2120 | 19000 | 28000 | 0.018 |
| d: 30 D: 30 B: 9 B1: 0.6 r(min): 0.3 |
7200C | 5820 | 2950 | 18000 | 26000 | 0.03 |
Additional Information
- Ideal for use in high-speed applications.
- Enhanced durability for extended operational life.
- Requires proper lubrication for optimal performance.
