SIZE 86mm?3° stepper motor
Inquire Now
step angle 3.0°
high reliability
| Model | |||||||||
| Current | Resistance | Inductance | Holding torque | Inertia | Length | Weight | |||
| A | Ω±10% | mH±20% | N.m | OZ.in | kg/cm2 | mm Max | Kg | Lbs | |
| 34G280-04S/D | 6.0 | 0.5 | 2.8 | 4.0 | 567 | 1.8 | 80 | 2.1 | 4.6 |
| 34G2120-04S/D | 6.0 | 0.7 | 6.0 | 7.2 | 1020 | 3.6 | 120 | 3.6 | 7.9 |
| 34G2120-05S/D | 7.5 | 0.5 | 4.0 | 7.2 | 1020 | 3.6 | 120 | 3.6 | 7.9 |
