Slim LED TV 17Aseries size from 40″ to 65″/DLED Digital Home TV/Voice Television/Ultra Slim LED TV
Inquire NowLow consumption of energy, eco-friendlyHigh definition picture qualitymulti-system and wide voltage from AC100-240V,?multi OSD language meets requirements of different countries.A grade panel and good quality mainboard mainly from CVTDynamic BacklightStereo speakersSupport RF in, VGA in, USB in, HDMI in, AV in, Ypbpr in, earphone out, PC audio in,TS/S2 tuner, Scart, coaxial, CI, DC adapter is optional ?Video system: PAL,SECAM,NTSCSmart function: android 4.4, 7.0,8.0 or 9.0 version is optional?DDR size:512M/1GFlash size: 4GB/8GSmart function support app of Google, Youtube , facebook etc.?Voice TV available
| Model | 17A Series | |||||||
| Size Available | 40″/50″/55″/65″ | |||||||
| PANEL | ||||||||
| Panel | A grade | |||||||
| Display type | TFT LED | |||||||
| Aspect ratio | 16:9 | |||||||
| Resolution | 40″-55″ 1920 x 1080 | |||||||
| 65″ 3840 x 2160 | ||||||||
| Dot Specification | 40″ 20% ,2/7/7 | |||||||
| 50″ 30% ,3/12/12 | ||||||||
| 55″ 30% ,3/12/15 | ||||||||
| 65″ 30% ,5/15/15 | ||||||||
| Brightness | 40″220±10% | |||||||
| 50″-65″250±10% | ||||||||
| Contrast | 3000:1 | |||||||
| Viewing angle | 176°(H) X 176°(V) | |||||||
| Maximum colors | 16.7M | |||||||
| Response time | 6.5ms | |||||||
| Sync Frequency | 60HZ | |||||||
| Backlight life | ≥30000 hrs | |||||||
| SYSTEM & FEATURES | ||||||||
| Colour system | PAL/SECAM | |||||||
| Sound system | BG/DK/I | |||||||
| Digital TV system | DVB-T/T2/S2,ATSC Optional | |||||||
| OSD language | English/French/Arabic/Russia/Farsi/Chinese/Spanish/Portuguese/German/Italian/Turkish | |||||||
| Comb filter | 3D | |||||||
| AV stereo | YES | |||||||
| OTHER FEATURES | ||||||||
| HDMI resolution | 480i/p,576i/p, 720p,1080i/p | |||||||
| YPrPb resolution | 480i/p,576i/p, 720p,1080i/P | |||||||
| VGA resolution | Up to 1920×1080 @60HZ | |||||||
| Cabinet | Aluminum | |||||||
| Stand base | Aluminum | |||||||
| Cabinet color | grey color | |||||||
| Wall mount | optional,add more $ | |||||||
| MAIN board | Optional | |||||||
| Smart | Optional(Android version 4.4/5.0/6.0/7.0/8.0/9.0 Optional) | |||||||
| RAM | 512M/1G/2G Optional | |||||||
| FLASH | 4GB/8G/16G Optional | |||||||
| CONNECTORS | ||||||||
| Antenna Input | ×1( FIN Type) | |||||||
| USB Input | ×2 for 40″; ×3 up 50″ | |||||||
| HDMI Input | ×2 for 40″; ×3 up 50″ | |||||||
| AV Input | ×1 | |||||||
| VGA Input | ×1 | |||||||
| PC AUDIO Input | ×1 | |||||||
| RJ45 IN | ×1 | |||||||
| YPBPR | ×1 | |||||||
| COAX | x1 | |||||||
| EARPHONE OUT | x1 | |||||||
| USB 2.0 SLOT | ||||||||
| USB Type | 2 | |||||||
| Video Support | MPEG1/2/4,H.264 | |||||||
| Audio Support | MP3 | |||||||
| Photo Support | JPG/JPEG | |||||||
| Hard Disk Support | 1TB | |||||||
| AUDIO | ||||||||
| Max Audio Output Power | 2*8W (8Ω) | |||||||
| Total number of speakers | 2 | |||||||
| POWER REQUIREMENTS | ||||||||
| Power Source | 100-240VAC 50/60HZ | |||||||
| Power ON consumption | 40″≤74W/50″≤120W/55″≤160W/60″220W | |||||||
| Standby consumption | ≤0.5W | |||||||
| Power Plug | VDE 2 roung pin plug | |||||||
| PACKING DETAILS | ||||||||
| Size | Carton Size | Carton Size | Loading Qnty(PCS) | N.W(KGS) | G.W(KGS) | |||
| L*W*H(mm) | L*W*H(mm) | 20’GP | 40’GP | 40’HQ | ||||
| 40”FHD | 902X237X567 | 964X126X584 | 428 | 880 | 880 | 6.70 | 8.80 | |
| 50”FHD/4K | 1124X269X699 | 1215X145X740 | 213 | 438 | 438 | 11.10 | 15.00 | |
| 55”FHD/4K | 1239X269X767 | 1324X146X792 | 130 | 270 | 405 | 13.60 | 17.70 | |
| 65”4K | 1458*269*889 | 1547X146X913 | 106 | 224 | 224 | 22.30 | 27.90 | |
