Slot Machine
Inquire NowDescription
Introducing the robust Slot Machine, designed for precision and durability. This machine features heavy cast iron construction, ensuring longevity and stability during operation. The swivel head can tilt left and right up to 90º, allowing for versatile machining angles. With a machining stroke range of 0-125 mm and a speed of 60-350 strokes per minute across six different ranges, this slot machine is ideal for various machining tasks.
Specifications
| Attribute | Details |
|---|---|
| Item No. | 376602 |
| Model | B5013 |
| Max. Stroke | 125 mm |
| Ram Stroke | 30-350 strokes/min, 6 steps |
| Work Table Size | 600 x 240 mm |
| Work Table Longitudinal Travel | 130 mm |
| Work Table Cross Travel | 340 mm |
| T-Slot | 14 mm |
| Head Swivel (Right and Left) | 90º |
| Motor Power | 0.25 kW |
| N.W./G.W. | 330 / 380 kg |
| Packing Size | 109 x 112 x 79 cm |
Additional Information
Standard Accessories: No.
Optional Accessories: No.
