SMT-3512
Inquire NowDescription
The SM Trinocular Microscope with Two Arms Boom Stand is a cutting-edge optical instrument designed to provide exceptional clarity and resolution in various applications. Featuring a modular design and two parallel beam paths, this microscope delivers distortion-free images across its entire zoom range. With an impressive zoom ratio of 8:1, the SM series is versatile, allowing users to customize their experience with a variety of packages tailored to specific needs. The microscope is equipped with a high-quality optical system that ensures high-resolution imaging, making it ideal for both professional and educational settings.
Specifications
| Attribute | Details |
|---|---|
| Zoom Range | 0.62x – 5x |
| Zoom Ratio | 8:1 |
| Magnification | 6.2x – 50x (with accessory lens: 1.9x – 250x) |
| Working Distance | 80mm (with accessory lens: 26mm – 278mm) |
| Field of View | 33.9mm – 4.2mm (with accessory lens: 106mm – 0.6mm) |
| Interpupillary Distance | 50mm – 75mm |
| Dioptric Correction | +5 to -5 |
| Eyepiece | WFH10X-D/21 High eye point, wide-field, distortion-free |
| Base Dimensions | 385x260x32mm |
| Vertical Post | OD. 37mm, main post 380mm, extension post 225mm |
| Horizontal Post | OD. 20mm, length 570mm, travel distance 15.5 – 37mm |
| Universal Arm (E-Arm) | 5/8” fitting, ID. of Ring 76mm for microscope body |
Additional Information
For optimal performance and longevity, it is recommended to handle the microscope with care and regularly clean the optical components. Ensure to use appropriate accessories when expanding the capabilities of the microscope.
