SOCMA 12T Diesel Engine Big Forklift for port
Inquire NowFujian Southchina Heavy Machinery Manufacture Co. Ltd-SOCMA-was founded in 2011, and locates in Quanzhou Fujian Province. SOCMA is dedicating in the research and manufacturing of material handling equipment and electric construction machinery. SOCMA takes the demand of the clients as its guide, engage in providing high cost-effectiveness products to clients.
| Item | HNF-120 | ||
| Features | Rated Load | Q(t) | 12 |
| Load center | c(mm) | 600 | |
| Wheelbase | y(mm) | 3000 | |
| Weight | Weight | kg | 18000 |
| Chassis | Tyre Specs.:Front | 10.00-20-16PR | |
| Tyre Specs.:Rear | 10.00-20-16PR | ||
| Tyres Qty,front/rear(X-drive wheels) | 42 | ||
| Wheel tread:Front | b10(mm) | 1650 | |
| Wheel tread:Rear | b11(mm) | 1970 | |
| Dimension | Mast/carriage tilt angle(front/rear) | Degree(°) | 612 |
| Mast height(fork lowering) | h1(mm) | 3100 | |
| Mast lifting height | h3(mm) | 3000 | |
| Max.lifting height | h4(mm) | 4600 | |
| Height to head guard(height to cab) | h6(mm) | 3000 | |
| Overall Length(with forks) | l1(mm) | 6055 | |
| Fork front vertical surface to the rear end of the vehicle | l2(mm) | 4855 | |
| Overall width | b1/b2(mm) | 2250 | |
| Fork Dimension | s/e(mm) | 1200X180X90 | |
| Fork carriage width | b3(mm) | 2200 | |
| Mast min ground clearance(with load) | m1(mm) | 225 | |
| Wheelbase center min ground clearance(with load) | m2(mm) | 350 | |
| Min.Turning radius | Wa(mm) | 4450 | |
| Travel speed(with load/without load) | km/h | 23/26 | |
| Performance | Max.lifting speed(with load/without load) | mm/s | 220/270 |
| Max.Lowering speed(with load/without load) | mm/s | 450/300 | |
| Traction | kN | 90 | |
| Grade ablity(with load/without load) | % | 20/22 | |
| Driving brake | Hydraulic clamp disc | ||
| Engine | Engine brand/model | Optional one | Yuchai engine |
| YC6J150-T301 | |||
| 6.494L 110KW 2200rpm | |||
| Optional two | Dongfeng Cummins | ||
| QSB4.5-C130 | |||
| 4.5L 97KW 2200rpm | |||
| Cylinder No. | 64 | ||
| Others | Transmission gears(Front/rear) | 22 | |
| Attachments working pressure | Mpa | 16 | |
| Attachments using oil amount | l/min | 40 | |
