Solar energy PV system MC4 Connector
Inquire NowDescription
The Solar Energy PV System MC4 Connector is designed to provide a reliable and efficient connection in photovoltaic systems. This connector model, named PV-LTM3/PV-LTM3-1, supports a wide range of applications with its robust construction and high-performance features. Engineered for optimal performance, it ensures a strong and efficient electrical connection that withstands various environmental challenges.
Specifications
| Attribute | Value |
|---|---|
| Model Name | PV-LTM3/PV-LTM3-1 |
| Connector System | Φ4mm |
| Rated Voltage | 1000V DC (IEC) |
| Rated Current | 17A (1.5mm²), 22A (2.5mm²), 30A (4mm, 6mm², 12AWG, 10AWG) |
| Test Voltage | 6kV (50Hz, 1min) |
| Ambient Temperature Range | -40℃ to +90℃ (EC), -40℃ to +75℃ |
| Upper Limiting Temperature | +105℃ |
| Degree of Protection (Mated) | IP67 |
| Degree of Protection (Unmated) | IP2X |
| Contact Resistance of Plug Connectors | 0.5mΩ |
| Safety Class | 2 |
| Contact Material | Brass, Tinned Copper Alloy |
| Insulation Material | PC/PPO |
| Flame Class | UL-90-V0 |
| Salt Mist Spray Test, Degree of Severity | IEC 60068-2-52 |
Additional Information
This MC4 Connector is designed for use in harsh environments, providing excellent insulation and resistance to various external factors. It is essential for those looking to maintain high efficiency in solar energy systems.
