Solar Panels
Electrical Characteristics at Standard Test Conditions (STC)
| Module Type | KYUN275-60P | KYUN270-60P | KYUN265-60P | KYUN260-60P | KYUN255-60P |
| Maximum Power- Pmpp (W) | 275 | 270 | 265 | 260 | 255 |
| Positive Power Tolerance | 0~3% | 0- 3% | 0~3% | 0- 3% | 0- 3% |
| Open Circuit Voltage – Voe (V) | 38 | 37.9 | 37.7 | 37.6 | 37.5 |
| Short Circuit Current – lsc (A) | 9.15 | 9.08 | 9.01 | 8.94 | 8.92 |
| Maximum Power Voltage -Vmpp (V) | 30.9 | 30.7 | 30.5 | 30.3 | 30.1 |
| Maximum Power Current – lmpp (A) | 8.91 | 8.8 | 8.69 | 8.58 | 8.47 |
Electrical data relates t o standard test condlUons (STC): lrradlance 1000WI m’ ; AM 1.5; cell temperature 25″C measuring uncertainty of power Is within ±3%. Certi fied In accordance with IEC61215,IEC61730?1/2 and UL 1703
Electrical Characteristics at Normal Operating Cell Temperature (NOCT)
| Module Type | KYUN275-60P | KYUN270-60P | KYUN265-60P | KYUN260-60P | KYUN255-60P |
| Maximum Power- Pmpp (W) | 211 | 198 | 195 | 192 | 188 |
| Maximum Power Voltage -Vmpp (V) | 28.4 | 283 | 282 | 28.1 | 28 |
| Maximum Power Current – lmpp (A) | 7.1 | 7.01 | 6.92 | 6.82 | 6.72 |
| Open Circuit Voltage – Voe (V) | 35.8 | 35.5 | 35.2 | 34.9 | 34.6 |
| Short Circuit Current – lsc (A) | 7.35 | 7.3 | 7.25 | 7.2 | 7.16 |
