SPD Surge Protective Device
Inquire NowSPD Surge Protective Device
Product Briefing
Function
Surge protective device is also know as surge protector or SPD in short.
Technical Parameter
|
Model name |
|
EBS6U |
|
Standard |
|
IEC61643-11 |
|
Poles |
|
1P, 2P, 3P, 4P |
|
Max. continuous operation AC voltage Uc |
|
275V AC |
|
Norminal discharge current (8/20μs) In |
|
20kA |
|
Maximum discharge current (8/20μs) Imax |
|
40kA |
|
Voltage protection level (L-N) Up |
|
1.8kV |
|
Response time (L-N) tA |
|
25ns |
|
Mounting |
|
36mm Standard Guide |
|
Cross section of wire (Min.) |
|
4mm2 |
|
Cross section of wire (Max.) |
|
35mm2 |
|
Casing material |
|
Thermoplastic UL94-V0 |
|
Dimension (L*W*H) |
|
90*70*54mm |
Applicable Working and bus bar connection
|
Ambient temperature |
|
-5~+40℃, the average value cannot exceed to +35℃ within 24h |
|
Altitude |
|
≤2,000m |
|
Relative humidity |
|
≤95% |
|
Pollution level |
|
II. |
|
Installation location |
|
Mount on the place where has no obvious vibration or impact |
