SPD Surge Protective Device
Inquire NowDescription
The SPD Surge Protective Device, commonly referred to as a surge protector or SPD, is an essential component for safeguarding electrical systems from voltage spikes and transients. This high-quality device is designed to protect sensitive electronic equipment by diverting excess voltage, ensuring the longevity and reliability of your devices.
DC Surge Protector provides robust protection in various applications, from residential to commercial settings. With its durable construction and advanced technology, this surge protector ensures optimal performance, making it a vital addition to any electrical system.
Specifications
| Parameter | Value |
|---|---|
| Model Name | EBS7UZ |
| Standard | IEC61643-11 |
| Poles | 2P / 3P |
| Max. Continuous Operation DC Voltage Uc | 500/600 DC / 1000V DC |
| Peak Current (10/350) Ipeak | 12.5kA |
| Environment Temperature Tu | -40~80℃ |
| Nominal Discharge Current (8/20μs) In | 20kA |
| Maximum Discharge Current (8/20μs) Imax | 40kA |
| Voltage Protection Level (L-N) Up | 1.5kV |
| Response Time (L-N) tA | 25ns |
| Mounting | 36mm Standard Guide |
| Cross Section of Wire (Min.) | 4mm² |
| Cross Section of Wire (Max.) | 35mm² |
| Casing Material | Thermoplastic UL94-V0 |
| Dimension (L*W*H) | 90*70*54mm |
Additional Information
Choosing our SPD surge protective device guarantees reliable performance and adherence to international safety standards, making it a smart investment for protecting your electrical infrastructure.
