Special Injection Molding Machine for Mobile phone accessories
Inquire NowDescription
Powerjet MP Series Phone Case Injection Molding Machine is a specialized equipment designed for the efficient manufacturing of mobile phone cases and accessories. Engineered for precision, this machine utilizes materials such as polycarbonate (PC), elastomers, and other raw materials to produce high-quality products. The MP series stands out for its lightweight design and high precision, making it ideal for intricate shapes that are challenging to mold.
**Key Features:**
- Increased 40% Injection Speed and Pressure: Perfectly suited for high-volume phone case production.
- Specialized Screw for PC & TPU: Addresses common issues such as yellowing and other material defects.
- SKD Distributor/Ring/Washer: Enhances durability and reduces the likelihood of cracking, extending machine lifespan.
- Hydraulic System Upgrade: Provides more power and higher manufacturing efficiency.
- Strengthened Platen Structure: Minimizes platen deformation for enhanced precision and stability.
Specifications
| Description | Unit | Value |
|---|---|---|
| Clamping Force | KN | 138 |
| Opening Stroke | mm | 360 |
| Max. Daylight | mm | 810 |
| Platen Size | mm | 620 x 620 |
| Space Between Bars | mm | 410 x 410 |
| Max. Mold Height | mm | 450 |
| Min. Mold Height | mm | 145 |
| Ejector Stroke | mm | 120 |
| Ejector Force | KN | 42 |
| Screw Diameter | mm | 32 |
| Injection Pressure | MPa | 223 |
| Shot Volume | cm³ | 129 |
| Screw Stroke | mm | 160 |
| Hydraulic System Pressure | MPa | 17.5 |
| Pump Motor Power | KW | 15 |
Additional Information
No additional information provided.
