ST brush alternator
Inquire NowDescription
The ST Brush Alternator is a versatile and efficient power generation solution, designed for both single-phase and three-phase applications. With an output range of 2kW to 60kW, this synchronous alternator is perfect for various industrial and commercial uses. Its reliable brush-type design ensures consistent performance, while its easy installation and maintenance features make it user-friendly. The alternator operates at a frequency of 50Hz or 60Hz, accommodating both 1500 and 1800 RPM settings. Built with a robust 4-pole construction, it also includes an IP21 insulation rating, ensuring durability and longevity in a variety of environments.
Specifications
| Attribute | Details |
|---|---|
| Output Power | 2kW – 60kW |
| Type | Synchronous Alternator |
| Frequency | 50Hz / 60Hz |
| RPM | 1500 / 1800 |
| Insulation Class | B |
| Protection Rating | IP21 |
| Design | 4-pole, brush type, full copper |
Additional Information
The ST Brush Alternator features an easy connection to power networks or other generators, ensuring reliability in energy supply. It has a balanced rotor equipped with two sealed ball bearings, providing smooth operation. Maintenance is straightforward with easy access to terminals and coupling bolts, making this alternator a practical choice for users.
