ST single phase A.C.synchronous used alternator
Inquire NowDescription
The ST single phase A.C. synchronous used alternator is a reliable power generating unit designed primarily for small capacity applications. Ideal for supplying electricity for lighting on ships and powering household electric devices in towns or villages, this alternator features a robust construction with drip-proof, salient pole rotating field. It utilizes high-quality electromagnetic and electrical materials, ensuring excellent performance and durability.
With a self-excitation and constant voltage type design, the alternator is equipped with Class E or B stator insulation and Class B rotor insulation. Its aesthetic appeal, consolidated construction, and ease of maintenance make it a preferred choice for various environments. The dimensions comply with IEC standards, making it suitable for use in Australia, Europe, America, and other regions when using model B end covers.
The ST alternator boasts harmonic wave self-excitation and automatic voltage control systems, providing reliable operation with excellent dynamic characteristics.
Specifications
| Attribute | Details |
|---|---|
| Speed | 1500 r/min |
| Insulation Class | Class B or F |
| Protection Class | IP44, IP54, IP55 |
| Cooling Method | IC0141 |
| Housing | Cast Iron, Aluminum |
| Output | 100% output |
| AC Motor Power | 75 kW |
| Rated Current | >30 |
| Phase | Three-Phase |
| Protection Feature | Totally Enclosed |
| Revolving Speed | 1000-1500 |
| Efficiency | IE 1 |
| Rated Voltage | 380 V |
| Frequency | 1500 |
Additional Information
Operating conditions for continuous operation of the generator include:
- Altitude: not exceeding 1000m
- Ambient temperature: -15℃ to 40℃
- Relative air humidity: not exceeding 90%
