Steam generator
Inquire NowDescription
The steam generator is a high-performance device designed to efficiently produce steam for various industrial applications. Built with robust materials, it features a tube side made from 15CrMoR and a shell side from 16MnR, ensuring durability and reliability under high pressure and temperature conditions. With certifications from ASME, ISO9001, and DNV Classification Society, this steam generator guarantees adherence to international safety and quality standards.
Engineered for optimal performance, it operates at a design pressure of up to 2.5 MPa on the management side and 0.7 MPa on the shell side. The design temperature ranges from -10℃ on the tube side to a maximum of 300℃ on the shell side, making it suitable for a variety of heating needs.
Its standard size measures Ф2000×6768×34, with heat exchange tubes of Φ32×2.0. Weighing in at 37 tons, this steam generator is a powerful solution for efficient steam production in industrial settings.
Specifications
| Attribute | Details |
|---|---|
| Material | 15CrMoR (tube side), 16MnR (shell side) |
| Design Pressure | 2.5 MPa (Management), 0.7 MPa (Shell side) |
| Design Temperature | -10℃ (tube side), 300℃ (shell side) |
| Standard Sizes | Ф2000×6768×34 (heat exchange tube Φ32×2.0) |
| Weight | 37 tons |
