2 冲程发动机

125cc EFI

200cc EFI

247cc EFI

280cc EFI

300cc EFI

54×54.5mm

64×54.5mm

72.5x60mm

76x60mm

79x60mm

铸铝

6 档齿轮箱, 4 档攀爬专用

Multi-disc oil wet adjustable spring preload

9z/48

9z/42

10z/42

Symmetric and centered silencer

Vertigo R2 design Stainless steel

125/200cc Racing geometry throttle body

Racing geometry throttle body

366gr Flywheel weight

Red anodized aluminium intercooler

Vertigo special design, adapted to frame shape

Electronic Fuel Injection

Integrated injection driver

Protocol CAN 2.0 B

Atmospheric pressure & Air temperature sensor

TPS (Throttle position sensor)

ECU controlled electronic water pump

25CrMo4 steel + aluminium 6082 subframe

Black Aluminium cast

Tech Factory 170mm stroke

Monoshock / swingarm, Vertigo design

swingarm combined with REIGER 2 way monoshock with compression, rebound and spring preload adjustment

170mm stroke

High volume capacity airbox

High capacity 2.3l, low and centered CG

Renthal Fatbar

Hydraulic Braktec system with 185mm disc

4 pistons

Morad Black 1.60 x 21″ with Vertigo design red hubs

Hydraulic system with 150mm FIM disc

2 pistons

Morad lightweight Black anodized 2.15×18″ with Vertigo red hubs

Dunlop D803GP

2010mm

1310mm

680mm

66.6kg

68kg
