supper silent generator 80kw/100kva with ATS and AMF control system sound proof type
Inquire NowDescription
Introducing the Super Silent Generator, a robust 80kw/100kva power solution equipped with an Automatic Transfer Switch (ATS) and an Automatic Mains Failure (AMF) control system. This soundproof generator is designed for optimal performance in any environment, ensuring minimal noise disruption while providing reliable energy supply.
Engineered with a brand-new brushless alternator and a heavy-duty steel base frame, this generator is built for durability and efficiency. The IP21/22 rated alternator features H insulation class, ensuring longevity even in demanding conditions. The generator also includes an industrial silencer with a flexible bellow and elbow, enhancing its soundproof capabilities.
Additional features include a high-performance radiator for temperature regulation, vibration dampers for stability, and a comprehensive set of filters for air, oil, and fuel. The generator is designed with an average 8-hour base fuel tank and includes standard tool kits along with complete operation and maintenance manuals.
Specifications
| NO. | Genset Model | Standby Power (KVA) | Rated Voltage | Rated Currency | Engine Model | Max Output (KW) | Speed (r/min) | Starting Method | Exciting Method | L*W*H (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | HRC-20CF | 27.5 | 400 | 36 | ZH4100D | 33 | 1500 | 12V | Brushless | 1800*840*1250 |
| 2 | HRC-24CF | 33 | 400 | 43.2 | ZH4100D | 33 | 1500 | 12V | Brushless | 1800*840*1250 |
| 3 | HRC-30CF | 41.25 | 400 | 54 | ZH4100ZD | 45 | 1500 | 12V | Brushless | 1800*840*1280 |
| 4 | HRC-40CF | 55 | 400 | 72 | R4105ID | 50.6 | 1500 | 12V | Brushless | 1850*750*1350 |
| 5 | HRC-50CF | 68.75 | 400 | 90 | R4105ZD | 61.6 | 1500 | 24V | Brushless | 1850*750*1350 |
| 6 | HRC-64CF | 88 | 400 | 115.2 | R6105ZD | 92.4 | 1500 | 24V | Brushless | 2480*750*1360 |
| 7 | HRC-75CF | 103.125 | 400 | 135 | R6105ZD | 92.4 | 1500 | 24V | Brushless | 2480*750*1360 |
| 8 | HRC-90CF | 123.75 | 400 | 162 | 6105AZLD | 121 | 1500 | 24V | Brushless | 2480*750*1430 |
| 9 | HRC-100CF | 137.5 | 400 | 180 | 6105AZLD | 121 | 1500 | 24V | Brushless | 2480*750*1430 |
| 10 | HRC-120CF | 165 | 400 | 216 | 6105IZLD | 145 | 1500 | 24V | Brushless | 2480*750*1430 |
| 11 | HRC-150CF | 206.25 | 400 | 270 | HD6126ZLD11 | 187 | 1500 | 24V | Brushless | 3150*1050*1650 |
| 12 | HRC-180CF | 247.5 | 400 | 324 | HD6126ZLD12 | 225 | 1500 | 24V | Brushless | 3150*1050*1650 |
| 13 | HRC-200CF | 275 | 400 | 360 | HD6126ZLD | 247 | 1500 | 24V | Brushless | 3150*1050*1650 |
Additional Information
- Includes a comprehensive set of tool kits and operation/maintenance manuals.
- Designed to operate smoothly with various optional components such as:
- Automatic Transfer Switch
- ABB and Schneider Breakers
- Water and Lub-oil Heater
- Fuel level sensor
- Low coolant level sensor
- External Daily Fuel Tank
- Water-Fuel Separator
- Controller options: Deepsea, DEIF, ComAP, Woodward
