Switching power adapter
Inquire NowDescription
The Switching Power Adapter is a versatile and efficient power supply solution designed to meet a wide array of electronic needs. With a maximum power output of 3W and an adjustable output voltage ranging from 5V to 36V, this adapter is perfect for powering various devices. The YLF3-2 model boasts a compact size and lightweight design, making it easy to transport and use in different settings. Built with safety features such as short circuit, over current, and over voltage protection, it ensures reliable operation under various conditions. Ideal for both home and office use, this power adapter supports multiple input options and complies with international safety standards.
Specifications
| Attribute | Details |
|---|---|
| Model | YLF3-2 |
| Power | 3W max. |
| Input | 100-120V or 220-240V AC47-63Hz |
| Output Voltage | 5-36V |
| Output Current | 0.1-0.2A |
| Input Current | 0.09A max. |
| Inrush Current | 65 Amps max. at 230VAC/50Hz, full load |
| Leakage Current | 0.25mA Max. at 264VAC input |
| No Load Power Consumption | < 1.5W |
| Protections | Short Circuit / Over Current / Over Voltage |
| Working Temperature | -20°C to 50°C |
| Working Humidity | 5%-90% RH non-condensing |
| Storage Temperature and Humidity | -40°C to +70°C, 5% to 95% RH, up to 5000 meters AMSL |
| Input Plug | EU, US, UK, AU, etc. as per customer choice |
| Certificates | CE, EMC, RoHS, REACH |
| EMI Emission | EN 55022/FCC Part 15, EN 61000-3-2, EN 61000-3-3 |
| EMS Immunity | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
| MTBF | 100,000 hours minimum at full load at 25°C ambient |
| Life Expectancy | 3-5 years |
| Dimension | 80×59×43mm |
| Weight | 290g |
| Packing | 50PCS/CTN, 46.5×29.5×25.5mm |
Additional Information
- Short Circuit Protection to Zero Voltage
- Over Voltage Protection at ≤Vout*150%
- Over Current Protection at 110%-180%
