OEM ODM TE160
Description
The TE160 is a robust and efficient air-cooled engine designed for various applications where reliability and performance are paramount. Featuring a single-cylinder design, it employs a 4-stroke OHV engine type, ensuring smooth operation and minimal emissions. With a displacement of 163 cc and a maximum power output of 5.5 HP at 3600 rpm, the TE160 delivers exceptional torque of 10.8 N.m at 2500 rpm, making it suitable for a variety of tasks.
Equipped with a non-contact transistorized ignition system and a recoil hand-operated starting mechanism, this engine is user-friendly and easy to start. The semi-dry, oil-bath air cleaner enhances its efficiency by providing optimal air filtration. Designed for durability, it has a fuel tank capacity of 3.6 liters and an oil capacity of 0.6 liters, ensuring long operational times with minimal refueling. The TE160 is a versatile choice for contractors, landscapers, and DIY enthusiasts alike.
Specifications
| Attribute | Details |
|---|---|
| Model | TE160 |
| Engine Type | Air-cooled 4 stroke OHV single cylinder |
| Bore X Stroke (mm) | 68 x 45 |
| Displacement (cc) | 163 |
| Compression Ratio | 8.5 : 1 |
| Max. Power Output (HP/rpm) | 5.5 / 3600 |
| Max. Torque (N.m/rpm) | 10.8 / 2500 |
| Ignition System | Non-contact transistorized ignition (T.C.I) |
| Starting System | Recoil and hand-operated |
| Air Cleaner | Semi-dry, oil bath, dual, double silent and cyclone type |
| Fuel Tank (L) | 3.6 |
| Oil Capacity (L) | 0.6 |
| Fuel Consumption (g/HP-hour) | 290 |
| Dimension (L x W x H) mm | 380 x 330 x 375 |
| G.W (Kg) | 16 |
| 20’FCL (pcs) | 620 |
