Description

The TXGN15S-12 is an advanced medium voltage high voltage ring network switch cabinet designed for reliability and safety in secondary substations of industrial and mining enterprises. This extensible modular combination is constructed from metal, offering a robust and durable solution for power distribution needs. The cabinet incorporates high-quality switch devices which include a load switch, Fluarc SF1 or SFset circuit breaker, and Rollarc 400 or 400D contactor, along with an isolation switch for enhanced operational safety.

This switch cabinet is ideal for installations in distribution rooms or box substations with cable connections from the front, facilitating ease of access and maintenance. The design prioritizes user convenience, as all control function elements are centralized on the front operating board, making operation straightforward. Additionally, various accessories such as relays, coils, and instrument transformers can be integrated within the cabinet.

Built for indoor installation, the TXGN15S-12 meets international and national standards, ensuring compliance and performance. It operates effectively in environments with temperatures ranging from -5°C to +40°C and at altitudes below 1000 meters.

Specifications

Additional Information

• Designed for easy installation and operation
• All control functions concentrated on the front operating panel
• Can be customized with additional accessories such as relays and transformers
