TILT TV WALL MOUNT

Inquire Now

The LP72-46T TV wall mount includes popular accessories needed to install and mount most 37’’-80’’ curved/flat panel TVs weighing up to 75kg/165lbs.Spring locks with release straps allow users to lock or release TV in a snap. Best of all, packaging is optimized for online sellers that desired the lowest shipping and storage costs. It features an open design which maximizes airflow to equipment and provides easy access to the back of components. In addition, its tilting system provides easy adjustment of viewing angle.

FEATURES

  • Reduced Package Size: relatively lower transport costs and strorage fees (perfect for e-commerce platform sellers)

  • Automatic Spring Locks with Quick Release Cords: allow TV removal quick and easy

  • Free-Tilting Design: makes easy forward or backward adjustment for better viewing and reduced glare

  • Open Architecture: provides increased ventilation and easier access to wires

SPECIFICATION

Product Category: Tilt TV Wall Mount
Rank: Standard
Material: Steel
Metal Sheet Thickness: Wall Plate THK=1.5mm cold-rolled sheet,Bracket Arm THK=1.5mm cold-rolled sheet (Wall Plate THK=0.059″ cold-rolled sheet,Bracket Arm THK=0.059″ cold-rolled sheet)
Surface Finish: Powder Coating
Color: Fine Texture Black
Dimensions: 37x641x420mm (1.5″x25.2″x16.5″)
Fit Screen Size: 37″-80″
Fit Curved TV: Yes
Mounting Hole Pattern : VESA & Universal
VESA Compatible: 150×100,150×150,200×100,200×200,200×400,300×200,300×300,350×350,400×200,400×300,400×400,600×200,600×300,600×400
Max. VESA: 600×400
Weight Capacity: 75kg (165lbs)
Strength Tested: 3 Times Approved
Profile: 37mm (1.5″)
Tilt Range: 0°~-8°
Installation: Solid Wall,Double Stud(406mm/450mm/600mm)
Panel Type: Detachable Panel
Wall Plate Type: Fixed Wall Plate
Direction Indicator: Yes
Accessory Kit Package: Compartment Polybag
