Description
The TL-450 Automatic Coil, Pin, and Plug Assembling and Welding Machine by Tongli Machinery is a state-of-the-art solution designed for efficiency in manufacturing. This multifunctional machine automates the assembly of coils and pins with plugs, ensuring precise resistance value testing. It also features the capability to weld terminal pins to coils without the need for grinding the electrode tip, even after producing up to 20,000 products. This innovative design enhances productivity while maintaining high-quality standards.
Specifications
| Parameter | Details |
|---|---|
| Power Supply | 3-phase 380V 50Hz |
| Power | 1000W |
| Air Supply | 6-8 kg/cm2 |
| Applicable Resistance Wire | Wire diameter ≥ φ0.2, coil length: 60-460mm |
| Applicable Terminal Pin Diameter | Diameter ≥ φ8, length: 45-120mm |
| Machine Size (L*W*H) | 1600 x 163 x 1600 mm |
| Gross Weight | 550 kg |
| Net Weight | 400 kg |
