Description
The TNB1L-32(b) Mini Circuit Breaker is an advanced Earth Leakage Protection (ELCB) device designed to safeguard electrical systems from ground faults. This compact safety breaker adheres to international standards IEC/EN 61008-1 and GB 16916.1, ensuring reliable performance in a variety of applications. Its patent design not only enhances functionality but also contributes to easy assembly and installation. The ELCB provides essential ground fault protection, making it a critical component for any electrical safety setup.
Specifications
| TNB1L-32 Series ELCB/RCCB | ||
|---|---|---|
| Product Code | TNB1L-32(b) | |
| Protection | Earth Leakage Protection (Ground Fault Protection) | |
| Rated Current | 16A, 20A, 25A, 32A | |
| Rated Residual Current | Operating, IΔn | 15mA, 30mA |
| Non-operating, IΔno | 7.5mA, 15mA | |
| Poles | 2 Poles | |
| Rated Voltage | 110V AC, 220V AC | |
| Residual Current Off-time | 0.1s | |
| Standard | IEC/EN 61008-1, GB 16916.1 | |
| Approval | CE, CCC | |
| Type of Trip | Ground Fault | Electronic |
| Rated Switch-on Breaking Capacity, Im | 500 A | |
| Rated Limited Short Circuit Current, Inc | 2.5 KA | |
| Endurance | Electrical: 1000 operations | |
| Material of Body | Base | Bakelite / Plastic |
| Cover in Grey Color | Plastic | |
| Cover in Black Color | Bakelite | |
| Type of Operation | AC | |
| Dimensions (L*W*H) | 70mm * 32mm * 53mm | |
Additional Information
- Compact size for easy installation.
- Designed for efficient ground fault protection.
- Patent design ensures reliability and longevity.
