Description
The TNB1L-32(c) 32A Water Heater RCCB is a compact and efficient mini safety breaker designed for earth leakage protection (ground fault protection). Conforming to the IEC/EN 61008-1 and GB 16916.1 standards, this innovative device is perfect for ensuring the safety of your electrical installations. Its patent design allows for easy assembly, making it a user-friendly choice for both professionals and DIY enthusiasts. The TNB1L-32(c) is not just compact; it brings reliability and safety to your electrical systems.
Specifications
| Attribute | Details |
|---|---|
| Product Code | TNB1L-32(c) |
| Protection | Earth leakage protection (Ground fault protection) |
| Rated Current | 16A, 20A, 25A, 32A |
| Rated Residual Current |
|
| Poles | 2 poles |
| Rated Voltage | 110V AC, 220V AC |
| Residual Current Off-Time | 0.1s |
| Standard | IEC/EN 61008-1, GB16916.1 |
| Approval | CE, CCC |
| Type of Trip | Ground fault (Electronic) |
| Rated Switch-On Breaking Capacity, Im | 500 A |
| Rated Limited Short Circuit Current, Inc | 2.5 KA |
| Endurance |
|
| Material of Body |
|
| Type of Operation | AC |
| Dimensions (L*W*H) | 70mm * 32mm * 53mm |
Additional Information
For optimal performance, ensure that the TNB1L-32(c) is installed by a qualified electrician. Regular maintenance checks are recommended to verify the functionality of the safety breaker.
