Tnb1l-32(f) 32A, Nt50 Panasonic Design Earth Leakage Protection ELCB

Inquire Now

Description

The TNB1L-32(f) is a high-performance Mini Safety Breaker designed for Earth Leakage protection, also known as Ground Fault protection. It adheres to the strict standards of IEC/EN 61008-1 and GB 16916.1, ensuring reliability and safety. This compact device is engineered for easy assembly and features a patented design that sets it apart in the market. Ideal for both residential and commercial applications, the TNB1L-32(f) provides peace of mind by effectively mitigating electrical hazards.

Specifications

TNB1L-32 series ELCB/RCCB
Product code TNB1L-32(f)
Protection Earth leakage protection (Ground fault protection)
Rated current 16A, 20A, 25A, 32A
Rated residual current Operating, IΔn 15mA, 30mA
Non-operating, IΔno 7.5mA, 15mA
Poles 2 poles
Rated voltage 110V AC, 220V AC
Residual current off-time 0.1s
Standard IEC/EN 61008-1, GB16916.1
Approval CE, CCC
Type of trip Ground fault Electronic
Rated switch-on breaking capacity, Im 500 A
Rated limited short circuit current, Inc 2.5 KA
Endurance Electrical 1000 operations
Mechanical 2000 operations
Material of body Base Bakelite / Plastic
Cover in grey color Plastic
Cover in black color Bakelite
Type of operation AC
Length*Width*Height 70mm * 32mm * 53mm

Additional Information

  • Compact size for easy installation
  • Patented design enhances functionality
  • Offers robust Earth Leakage protection for enhanced safety
