Tower Crane TC6520
Inquire NowDescription
The Tower Crane TC6520 represents the pinnacle of modern engineering, integrating advanced technology into its design and functionality. This crane is engineered to meet global standards in raw material usage, structural design, operational mechanisms, control systems, efficiency, safety, and reliability. With parts designed using three-dimensional software and rigorous force calculations, the TC6520 guarantees exceptional safety and performance, making it an indispensable tool for large-scale construction projects.
Specifications
| Attribute | Value |
|---|---|
| Independent height (m) | 53 |
| Max height with attachment (m) | 203 |
| Adjustable working range (m) | 55, 60, 65 |
| Min working range (m) | 2.5 |
| Max lifting capacity (t) | 12 |
| Tip load @ 65m (t) | 2.0 |
| Hoist mechanism falls | 2 |
| Hoist mechanism lifting capacity (t) | 0-10 |
| Speed (m/min) | 0-100 |
| Motor | YZRSWF280M-4/8 55/55KW |
| Climbing speed (m/min) | 0.5 |
| Counterweight (t) | 23.6 |
| Mast section size (m) | 2 x 2 x 3 |
| Working temperature (°C) | -40 to +60 |
| Power supply requirement (KVA) | 220KVA for generator, 235KVA for transformer booster |
| Cable type (25 meters) | 50mm² (3+2, 5 cores) |
| Startup voltage & current | 380V × 0.95=361V 260A |
| Rated working voltage & current | 380V 150A |
Loading Diagram
For a jib length of 65m, the following loading capacities apply:
| R | a=2 (t) | a=4 (t) |
|---|---|---|
| 50 | 5t—29.1m | 12t—14.73m |
| 52 | 4.84 | 7.33 |
| 54 | 4.1 | 5.8 |
| 56 | 3.53 | 4.77 |
| 58 | 3.02 | 4.03 |
