TR Series 150mm2 Aluminum/Copper Al/Cu Cable, Grey Universal Terminal Block

Inquire Now

Description

The TR Series 150mm² Aluminum/Copper (Al/Cu) Universal Terminal Block is designed for versatile applications in electrical installations. It ensures high-quality, safe connections for both copper and aluminum conductors with a cross-section area of up to 240 mm². This terminal block combines compact design with robust performance, making it an essential component for reliable electrical connections.

The TR series terminal block features a user-friendly mounting system, easily attached to DIN rails or secured with screws. It is engineered with hexagonal screws to provide a strong and secure tightening mechanism. Crafted from durable polyamide that complies with UL 94 standards, it guarantees longevity and dependable performance in various environments.

Specifications

Attribute Details
Conformity CE, RoHS
Standards EN 60947-7-1 / EN 61238-1
Cross Section Area Al 6-240 mm² / Cu 2.5-240 mm²
Nominal Current Range 145A-425A
Housing Material UL 94 V-0 Polyamide
Metal Body Tinned Aluminum
Screws Steel
Screw Heads Hexagonal
Mounting Options DIN Rail or Screws

Additional Information

  • Compact Size: Designed for space-saving installations.
  • Easy Mounting: Quick installation on DIN rails or with screws.
  • Reliable Tightening: Ensures secure connections with hexagonal screws.
  • Durable Material: Made from high-quality polyamide for long-lasting use.
