Trl-40(b) 40A, Nt50 Panasonic Design Earth Leakage Protection ELCB
Inquire NowDescription
The TRL-40(b) is a high-performance mini safety breaker designed for Earth Leakage Protection (Ground Fault Protection). Its compact design makes it an ideal choice for various applications, ensuring safety without sacrificing space. This device adheres to international safety standards, specifically IEC/EN 61008-1 and GB 16916.1, making it a reliable option for both residential and commercial settings.
Key advantages include:
- Compact size for easy installation
- Simple assembly process
- Innovative patent design
This ELCB is available in various rated currents, accommodating a wide range of electrical needs.
Specifications
| Feature | Details |
|---|---|
| Product Code | TRL-40(b) |
| Protection | Earth leakage protection (Ground fault protection) |
| Rated Current | 16A, 20A, 25A, 32A, 40A |
| Rated Residual Current |
Operating, IΔn: 15mA, 30mA Non-operating, IΔno: 7.5mA, 15mA |
| Poles | 2 poles |
| Rated Voltage | 110V AC, 220V AC |
| Residual Current Off-Time | 0.1s |
| Standard | IEC/EN 61008-1, GB16916.1 |
| Approval | CE, CCC |
| Type of Trip | Ground fault (Electronic) |
| Rated Switch-On Breaking Capacity, Im | 500A |
| Rated Limited Short Circuit Current, Inc | 2.5 KA |
| Endurance |
Electrical: 1000 operations Mechanical: 2000 operations |
| Material of Body |
Base: Plastic Cover in Grey Color: Plastic Cover in Black Color: Bakelite |
| Type of Operation | AC |
| Dimensions (L*W*H) | 70mm * 32mm * 51mm |
Additional Information
This product’s unique features and compliance with safety standards make it an essential component for any electrical system requiring reliable ground fault protection. The TRL-40(b) is engineered for durability and ease of use, ensuring peace of mind in any installation.
