TRL-40(c) 40A, Nt50 Panasonic Design High Quality Earth Leakage Protection Switch

Inquire Now

Description

The TRL-40(c) is a high-quality Earth Leakage Protection Switch designed to provide reliable safety in electrical systems. This mini safety breaker offers essential ground fault protection, ensuring that any leakage current is detected promptly, thus preventing potential hazards. Built in accordance with IEC/EN 61008-1 and GB 16916.1 standards, it combines a compact design with ease of assembly, making it a perfect choice for both residential and commercial applications. Its patented design ensures durability and efficiency, providing peace of mind for users.

Specifications

TRL-40 series ELCB/RCCB
Product code TRL-40(c)
Protection Earth leakage protection (Ground fault protection)
Rated current 16A, 20A, 25A, 32A, 40A
Rated residual current Operating, IΔn 15mA, 30mA
Non-operating, IΔno 7.5mA, 15mA
Poles 2 poles
Rated voltage 110V AC, 220V AC
Residual current off-time 0.1s
Standard IEC/EN 61008-1, GB 16916.1
Approval CE, CCC
Type of trip Ground fault Electronic
Rated switch-on breaking capacity, Im 500A
Rated limited short circuit current, Inc 2.5 KA
Endurance Electrical 1000 operations
Mechanical 2000 operations
Material of body Base Plastic
Cover in grey color Plastic
Cover in black color Bakelite
Type of operation AC
Length*Width*Height 70mm * 32mm * 51mm

Additional Information

  • Compact size for easy installation.
  • Patented design for enhanced performance.
  • Meets international safety standards for peace of mind.
